Maintenance-free due to durable ultracaps
Micro-controller supported charging and discharging of the ultracaps
Operation monitoring and charge status monitoring by LEDs
Fast charging by active current charging control
IPC management by time triggered and output current triggered shutdown function Numerous customer-specific parametrization settings by USB interface
| energy | 13,4 kJ |
| rated input voltage | 24 V (SELV/PELV) |
| decoupled | 23,9 - 27 V DC ±0 % |
| not decoupled | 23,4 - 27 V DC ±0 % |
| rated output voltage | 24 V DC |
| output voltage in back-up model | 23,2 V DC ±2 % |
| nominal output current | 10 A |
| dimensions (H x B x T) | 172,4 mm x 116 mm x 143 mm |
| weight | 2,2 kg |
