Maintenance-free due to long-life ultracapacitors
Microcontroller-supported charging and discharging of the ultracapacitors
Operating and charging status monitoring via potential-free contacts and LEDs
Capacity can be extended by external capacitor modules
"Ue-o.k." Message via USB
Maintenance-free due to long-life ultracapacitors
Microcontroller-supported charging and discharging of the ultracapacitors
Operating and charging status monitoring via potential-free contacts and LEDs
Capacity can be extended by external capacitor modules
"Ue-o.k." Message via USB
| energy | 2 kJ |
| rated input voltage | 24 V (SELV/PELV) |
| decoupled | 23,9 - 27 V DC ±0 % |
| not decoupled | 23,4 - 27 V DC ±0 |
| rated output voltage | 24 V DC |
| nominal output voltage in buffer operation | 23,2 V DC ±2 % |
| max. nominal output current | 10 A |
| dimensions (h x w x d) | 172 mm x 70 mm x 143 mm |
| weight | 1,3 kg |
