UPS battery with a service life of 10 years - J.Schneider

Battery Life Duration up to 10 years

can be installed in any position (but not upside down)
impact- and break-proof plastic housing made of ABS
valve-regulated construction, almost 100% oxygen recombination during each charging process
electrolyte bound in glass fibre fleece
no refilling of electrolyte necessary
corrosion-resistant high-performance grid plates with lead-calcium alloy
wide operating temperature range with corresponding temperature-dependent voltage compensation
very good charging efficiency
no dangerous goods according to IATA
conformity to EN 61056-2
long life with low self-discharge, 3% per month at 20°C

Art.-no. : 452011.xxx

Name	SBV 17-12
article number	452011.2
VdS number	G108006
nominal voltage	12 V
capacity	17 Ah
life duration according to Eurobat	5 years
dimensions (h x w x d) / weight	167 x 76 x 181 mm / 6,1 kg

name	SBV 24-12
article number	452011.4
VdS number	G108007
nominal voltage	12 V
capacity	24 Ah
life duration according to Eurobat	5 years
dimensions (h x w x d) / weight	125 x 175 x 166 mm / 7,8 kg

name	SBV 40-12
article number	452011.8
VdS number	G108008
nominal voltage	12 V
capacity	40 Ah
life duration according to Eurobat	5 years
dimensions (h x w x d) / weight	197 x 165 x 170 mm / 15,7 kg

name	SB 45-12
article number	452011.xx
VdS number	G112060
nominal voltage	12 V
capacity	45 Ah
life duration according to Eurobat	10 - 12 years
dimensions (h x w x d) / weight	197 x 165 x 170 mm / 15,7 kg

name	SBV 65-12
article number	452011.9
VdS number	G114035
nominal voltage	12 V
capacity	65 Ah
life duration according to Eurobat	5 years
dimensions (h x w x d) / weight	174 x 166 x 350 mm / 24 kg

name	SBV 80-12
article number	452011.60
nominal voltage	12 V
capacity	80 Ah
life duration according to Eurobat	10 years
dimensions (h x w x d) / weight kg	180 x 167 x 350 mm / 24,5 kg

name	SBV 100-12
article number	452011.40
nominal voltage	12 V
capacity	100 Ah
life duration according to Eurobat	10 years
dimensions (h x w x d) / weight kg	222 x 172 x 330 mm / 30,5 kg

name	SBV 120-12
article number	452011.53
nominal voltage	12 V
capacity	120 Ah
life duration according to Eurobat	10 years
dimensions (h x w x d) / weight	222 x 172 x 330 mm / 32,5 kg

name	SBV 150-12
article number	452011.59
nominal voltage	12 V
capacity	150 Ah
life duration according to Eurobat	10 years
dimensions (h x w x d) / weight	240 x 172 x 485 mm / 47 kg

name	SBV 200-12
article number	452011.6
nominal voltage	12 V
capacity	200 Ah
life according to Eurobat	10 years
dimensions (h x w x d) / weight	223 x 240 x 522 mm / 65 kg
