proSAFE D 1500 - 3000

Line-Interactive UPS system according to IEC / EN 62040-3 (VI-SS-311)



- LCD display

- Sinusoidal inverter

- RS232 and USB interface

- Slot for communication boards

- Powershare

- Hotswap for the battery

- terminal protected against overvoltage for telephone- or mains connection

-  shutdown software for Windows 95/98/NT/2000/XP, Linux and Novell systeme software



Art.-no. : 437042.xxx

Technical Data

nominal input voltage 230 V AC (selectable 220, 230, 240 V)
input frequency range 50 Hz or 60 Hz automatic recognition
output voltage 230 V AC (selectable 220, 230, 240 V)
waveform sinusoidal

Rating and back-up time of the proSAFE D 1500 - 3000 VA models

proSAFE D 1500

rating 1500 VA 1050 Watt
back-up time 6 minutes at 100 % load 15 minutes at 50 % load
rating 2200 VA 1540 Watt
back-up time 5 minutes at 100 % load 14 minutes at 50 % load
rating 3000 VA 2100 Watt
back-up time 5 minutes at 100 % load 14 minutes at 50 % load
